LINCOLN OUTBACK 185

The Lincoln Outback® 185 is a robust and portable engine-driven welder/generator, designed for professionals who require reliable performance in the field. With its compact design and versatile capabilities, it's ideal for service trucks, maintenance crews, farmers, and ranchers.

Key Features:

• DC Stick Welding Output: Delivers up to 185 amps of smooth DC welding output, suitable for welding steel, stainless steel, cast iron, or hardfacing projects with up to 5/32 in. (4 mm) stick electrodes .
• AC Generator Power: Provides 5,700 watts peak and 5,200 watts continuous AC generator power, capable of running grinders, work lights, pumps, and other tools .
• Kohler® CH440 Engine: Powered by a 14 HP, 1-cylinder, air-cooled gasoline engine with electric start and recoil backup, ensuring reliable performance in various conditions .
• Low-Lift™ Grab Bars: Patent-pending design provides more leverage for lifting the unit on and off truck beds, offering extra protection against product damage .
• Front Control Panel: All engine controls are conveniently located on the front panel, including the electric start switch and engine choke control, for easy access .
• Rugged Tube Frame: Constructed with a 1-1/4 in. (32 mm) diameter frame for sturdy protection and durability .
• Large Fuel Tank: Equipped with a 6.8-gallon (25.7-liter) fuel tank, allowing for extended run times and less frequent refueling .

Specifications:

• Welding Output Range: 50–185A DC
• Rated Output: 100A DC/25V/100% duty cycle; 130A DC/25V/60% duty cycle; 150A DC/25V/20% duty cycle .
• Generator Output: 5,700 watts peak; 5,200 watts continuous
• Engine: Kohler® CH440, 14 HP at 3,600 RPM
• Fuel Tank Capacity: 6.8 gallons (25.7 liters)
• Dimensions (H x W x D): 25.6 x 21.8 x 31.5 inches (651 x 553 x 800 mm)
• Weight: 295 lbs (134 kg)

The Lincoln Outback® 185 combines portability, power, and ease of use, making it a reliable choice for various welding and power generation needs in outdoor environments.

Call Burnback Welding today on 08 9434 1000 to place your order.

Our team is here to help you choose the right configuration and answer any questions about this machine.
